Karma Blazer Sling Powered Wheelchair
The Karma Blazer Sling is a compact and versatile powered wheelchair designed to deliver a balance of outdoor performance and indoor manoeuvrability. Its narrow 60cm width makes it highly practical for navigating tight spaces such as doorways, lifts, and confined indoor environments, while still offering strong performance outdoors.
Karma Blazer Sling Indoor and Outdoor Performance
The Karma Blazer Sling features strong motors and a 2-wheel suspension system that improves comfort and stability when travelling over uneven terrain. This makes it suitable for users who require reliable performance both in urban environments and more demanding outdoor conditions.
Karma Blazer Sling Comfort and Seating Adjustability
The seating system offers a range of adjustability options to support user comfort and positioning. The seat depth can be adjusted from 41cm to 46cm, while the back angle can be configured from -1° to 14°. A contour-adjustable headrest provides ergonomic support for the neck, with both height and angle adjustment available.
The optional power tilt system allows adjustments from 4° to 25°, helping redistribute pressure and improve long-term comfort.
Practical Design Features
The Karma Blazer Sling includes flip-back armrests for easier transfers and improved access to tables or desks. The detachable swing-away footrests require no tools and support easier entry and exit. Multiple leg and foot support options are available, including elevating legrests and amputee support configurations.
For improved safety, the wheelchair is equipped with an LED lighting system for better visibility in low-light conditions.
Safety and Transport
The Karma Blazer Sling is crash test approved to ISO 7176-19 standards, making it suitable for use as a seat during motor vehicle transport when properly secured.
Specifications:
| Product Name | KP-31-SLN(17″) | KP-31-SLN(19″) | KP-31-SLN(T)(17″) | KP-31-SLN(T)(19″) |
| Seat Width (mm) | 430 | 480 | 430 | 480 |
| Seat Depth (mm) | 410/435/460 | 410/435/460 | 410/435/460 | 410/435/460 |
| Front Seat Height (mm) | 440 | 440 | 440 | 440 |
| Backrest Height (mm) |
430 | 430 | 430 | 430 |
| Seat Angle (X°) | 4 | 4 | 4 | 4 |
| Back Angle (X°) | (-1)~14 | (-1)~14 | (-1)~14 | (-1)~14 |
| Armrest Height (mm) |
180~280 | 180~280 | 180~280 | 180~280 |
| Legrest Length (mm) |
320~460 | 320~460 | 320~460 | 320~460 |
| Power Functions | power Tilt：4°~25° | power Tilt：4°~25° | ||
| Suspension | Rear | Rear | Rear | Rear |
| Front/Middle/Rear Wheel (inch) |
9/-/14 | 9/-/14 | 9/-/14 | 9/-/14 |
| Controller | VR2 | VR2 | VR2 | VR2 |
| Motor (W) | 300 | 300 | 300 | 300 |
| Battery (Ah) | 50 *2 | 50 *2 | 50 *2 | 50 *2 |
| Min. Turning Radius (mm) | 820 | 820 | 820 | 820 |
| Min. Ground Clearance (mm) | 70 | 70 | 70 | 70 |
| Max Safe Slope | 10° | 10° | 10° | 10° |
| Max. Obstacle Height (mm) | 60 | 60 | 60 | 60 |
| Max. Speed (km) | 10 | 10 | 10 | 10 |
| Max Driving Range (km) | 30 | 30 | 30 | 30 |
| Max. User Weight (kg) | 136 | 136 | 136 | 136 |
| Weight w/ Batteries (kg) |
92 | 92 | 94 | 94 |
| Weight w/o Batteries (kg) |
62 | 62 | 64 | 64 |
| Overall L x W x H (mm) |
1070*600*930 | 1070*600*930 | 1070*600*1310 | 1070*600*1310 |
| Crash Tested | Yes | Yes | Yes | Yes |
